MOTM 830 Construction
"Dual Mode Mixer"



The first module we built was a MOTM 900 power module - kind of makes sense - it's one of the simplest (Paul Schrieber rated it as a "1" by  on his scale of 1-5 difficulty) and it could provide power to other modules as we build them.  Later on, we modified both our MOTM 900 & 950 modules so that our synth only needed one power cord and so that the power was distributed nicely - click here.

Now - the 800 EG Module is also rated a "1," but we'd decided to add Scott Juskiw's daughter boards and LEDs to our 800s, so we figured it's no longer a "1" at all.

So The MOTM 830 looked like a relatively simple next module to build.  We figured it'd give us experience at all the essential elements - PCB with resistors, capacitors etc., coax, wire, jacks, switches, and knobs and stuff.

For those who are constructing an 830, please check out Larry Hendry's MOTM-830 construction photos by way of cross-reference.

Table of Contents

This page has become really long, so here's a table of contents that we hope will make it easier to traverse:

Background - presents an explanation and Paul Schrieber's initial description of the Module with a couple photos from Larry Hendrey

Parts - presents a Bill of Materials for "two-dot-oh" builders and notes about it

Panel - presents the MOTM format panel

Construction Phase 1 - Resistors, Capacitors, IC Sockets, Power Plugs, MTA headers

Construction Phase 2 - Trimmers, Panel connections

Set up / Testing

Use notes

Background

Paul Writes:

The MOTM-830 is a dual mode (audio and/or control voltage) mixer. Using a clever switching scheme, the mixer can configure itself into either 6:1 or dual 3:1 mixers. The mixer is "split" when a patchcord is inserted into the OUT 2 jack.

The MOTM-830 is unique in the modular world: it is optimized for both audio signal quality and DC stability. Other mixers are generic, TL072-type mixers which are OK for audio but suffer from input offset voltage drift over temperature. The MOTM-830 uses special circuitry to provide superior audio specs (less than 0.005% THD, greater than 90dB SNR) while having superior DC specs (less than 1uV/C drift). Other features include:

  • Shielded cables on ALL signals
  • DC Bias generator: module can act as DC source!
  • Mixer #1 (IN1 - 3) uses linear pots, while Mixer #2 (IN4 - 6) uses audio taper pots
  • All pots are sealed, conductive plastic for long life and low noise


photo from Larry Hendry

Parts

In 2008 (or about that time), Synthesis Technology stopped producing full-blown kits, and moved toward what Paul calls "2.0" (two-dot-oh) DIY. This assumes the builder will buy certain parts from Synthesis Technology - PCB, Panel, and in some cases a Special Parts Kit of the particularly hard to find parts - and will get the rest of the parts from Mouser or Digikey or - well - wherever.

For those who are building this as a "two-dot-oh" project, Will and I, with feedback and review from others, have developed a parts-list / bill-of-materials in the form of an XL spreadsheet (as usual).

Please don't take it as gospel. We've been over and over it and are relatively confident in our specifications - and we hear that several people have used it successfully so you should be good.  The BOM assumes that you get the "extra parts kit" from Synthesis Tech.  Synthesis Technology offers some parts like pots and knobs at particularly good prices... these options are offered in the BOM.

Click here to download our XL spreadsheet Parts List

Panel

If you're building this as a "two-dot-oh" project, we also assume you get the panel from Synthesis Technology:- we'd show a picture here, but we don't have one <shrug>.

Construction Phase 1


ready to begin


stuffing resistors... for a table of resistor value markings click here.


soldering resistors

As usual with us, whereas we are vigilant about orienting all the resistors, caps, etc. consistently so their values can be read easily (in case we need to trouble-shoot them later), we oriented the resistors with the "Tolerance" stripe on the left (relative to the text on the pcb).  Why did we do it this way?  'Cause the gold stripe is so pretty and easy to see (of course)... and so we put it on the left - well - just because.  You might want to do it the opposite way.  (For the table of resistor value markings click here.)


washing the PCB


drying the PCB


the caps are in!


via holes


integrated circuits


cleaning the board


the board so far

It should probably be noted that whereas we have been vigilant about orienting all the resistors, caps, etc. consistently so their values can be read easily (in case we need to trouble-shoot them later), we oriented the resistors with the "Tolerance" stripe on the left (relative to the text on the pcb).  (For that table of resistor value markings click here.)  You might want to do it the opposite way.

OK - time for a break

Snack - Italian Sausage
with hot peppers and potatoes

We decided to try to re-create a recipe we adore for fried sweet Italian sausage with hot peppers and potatoes.


we started with some bacon (our addition to the recipe) - fried the sausage - then the hot peppers


time for the potatoes (we nuked them first to cook them through, but if you cut them real thin you can do without that) - a pint or two will wash this all down nicely


woah, baby!


ah!

Construction Phase 2

In the couple days it took for us to actually get back to the project, we had decided to apply Scott Juskiw's 830 modifications to our module.  So we unsoldered R8, 17, and 18 and replaced them with the values Scott suggested.


ready to go with the board-mounted pots


we solder in the coax

We didn't know it yet, but we had made a mistake in how we did this. We soldered the wires kind-of sticking up because we missed Paul's instruction about tying them down.  They should look like the photo on Larry Hendry's site.  As you'll see, we went back and corrected the wiring later - but for now -


we've moved onto the next step of soldering on the other wires.

The photo above is a great shot of our mistake - the coax is sticking straight up - it should be lying down and be tied.  Here's what we suggest for others.

Paul has stripped the coax so that the length of the non-braided wire is pretty near perfect for how he intends the coax to be soldered.  We suggest you insert both the non-braided and braided wires into their respective holes, solder the non-braided first, then press the coax down against the board so that the braided wire sticks completely through the PCB - then solder it.


We start on the jacks


jack orientation


bridging the top and angled jack contacts


standoff hardware


the PCB mounted to the mounting bracket
for more detail, click here


bracket attaches to the face plate


looks great... but then we realized our coax mistake


So we took the mounting bracket back apart and corrected the coax.  Not as pretty as if we'd done it correctly first thing, but - <shrug> -


It really wasn't difficult.


switch soldered


shrink wrap down


switch done


wiring the jacks column 1


wiring the jacks column 2


wiring the jacks column 3


wiring the jacks column 4


the blue pots didn't fit the holes - so we filed the holes just a tiny bit with our rat-tail file.  Then it worked fine.


soldering the wires


construction is done
